Medical Instruments EPQ High Temperature Resistance Wire SS Forming Wire
Medical Instruments EPQ High Temperature Resistance Wire SS Forming Wire
Basic Properties
Place of Origin:
China
Brand Name:
Toponewire
Certification:
ISO9001:2015
Model Number:
201/302/304/316/316L
Trading Properties
Minimum Order Quantity:
500KG
Payment Terms:
D/P, Western Union, L/C, T/T
Supply Ability:
500kg per month
Product Summary
SUS 302 304 316 310 Material EPQ Stainless Steel Wire Product Name SUS 302 304 316 310 Material EPQ Stainless Steel WireSurfaceBright StandardAISI DIN GB JISTreatmentcold-drawn, soft annealedDiameter0.8-15mm 1) We are a professional stainless steel wire factory for over 20 years;2) Mill Test ...
Product Custom Attributes
Highlight
high tensile stainless steel wire
,epq stainless steel wire
,904 stainless steel forming wire
Material:
Stainless Steel
Diameter:
0.15-12mm
Surface:
Bright Or Soap Cotaed
Packing:
By Customer Request
Standard:
JIS G. EN. ASTM. DIN. GB Etc
Supply Ability:
>500 Tons Per Month
Product Description
Detailed Specifications & Features
SUS 302 304 316 310 Material EPQ Stainless Steel Wire
| Product Name | SUS 302 304 316 310 Material EPQ Stainless Steel Wire |
| Surface | Bright |
| Standard | AISI DIN GB JIS |
| Treatment | cold-drawn, soft annealed |
| Diameter | 0.8-15mm |
1) We are a professional stainless steel wire factory for over 20 years;
2) Mill Test Certificate is supplied with shipment. If needed, a Third Party Inspection is acceptable.
3) We promise, if the chemical elements isn't up to the national standard or as said in the contract, we'll refund 100% payment.
Mechanical properties
| TENSILE STRENGTH(MPA) | ELONGATION(%) | ||
| | | FOR SOFT-ANNEALED WIRE ONLY | |
| 0.20~0.30 | 640~980 | _ | _ | ≥20 |
| 0.30~0.60 | 590~930 | _ | _ | ≥20 |
| 0.60~1.00 | 540~880 | 830~1180 | 1180~1520 | ≥25 |
| 1.00~3.00 | 490~830 | 780~1130 | 1130~1470 | ≥25 |
| 3.00~6.00 | 490~830 | 730~1080 | 1080~1420 | ≥30 |
| 6.00~14.00 | 490~790 | 730~1030 | _ | ≥30 |
Physical Properties
| Diameter Tolerance & Oval Tolerance | Mechanical Properties | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|
Chemical Composition
| AISI Grade | Chemical Composition(%) | |||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | |
| 304 | =<0.08 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 8.00~10.50 | 18.00~20.00 | - |
| 304H | >0.08 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 8.00~10.50 | 18.00~20.00 | - |
| 304L | =<0.030 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 9.00~13.50 | 18.00~20.00 | - |
| 316 | =<0.045 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 10.00~14.00 | 10.00~18.00 | 2.00~3.00 |
| 316L | =<0.030 | =<1.00 | =<2.00 | =<0.045 | =<0.030 | 12.00~15.00 | 16.00~18.00 | 2.00~3.00 |
| 430 | =<0.12 | =<0.75 | =<1.00 | =<0.040 | =<0.030 | =<0.60 | 16.00~18.00 | - |
| 430A | =<0.06 | =<0.50 | =<0.50 | =<0.030 | =<0.50 | =<0.25 | 14.00~17.00 | - |
How to Enquiry Topone Stainless Steel EPQ Wire in Efficiency
In order to quote you asap with right material in good price,we need you quote us with 10 details below .If you only know parts of them or only the wire application, you can talk with us online for help:
|
